MODULE
|
|
|
Name
|
Teltonika TM2500 |
|
Technology
|
GSM/GPRS/GNSS/BLUETOOTH |
|
GNSS
|
|
|
GNSS
|
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
|
Receiver
|
33 channel |
|
Tracking sensitivity
|
-165 dBM |
|
Accuracy
|
< 2.5m CEP |
|
Hot start
|
< 1 s |
|
Warm start
|
< 25 s |
|
Cold start
|
< 35 s |
|
CELLULAR
|
|
|
Technology
|
GSM |
|
2G bands
|
Quad-band 850 / 900 / 1800 / 1900 MHz |
|
Data transfer
|
GPRS Multi-Slot Class 12(up to 240 kbps) |
|
Data support
|
SMS (text/data) |
|
POWER
|
|
|
Supply voltage range
|
10 - 30 V DC with overvoltage protection |
|
Back-up battery
|
170 mAh Li-Ion battery 3.7 V (0.63 Wh) |
|
BLUETOOTH
|
|
|
Specification
|
4.0 + LE |
|
Supported peripherals
|
Temperature and Humidity sensor, Hands-free headset, Inateck Barcode Scanner, Universal BLE sensors support |
|
INTERFACE
|
|
|
Connection
|
Cigarette lighter socket |
|
GNSS antenna
|
Internal High Gain |
|
GSM antenna
|
Internal GSM High Gain |
|
USB
|
1 x USB 2.0 Micro-USB for configuration 1 x USB type A for external device charging (5V 1A) |
|
LED indication
|
RGB LED |
|
SIM
|
Nano-SIM |
|
Memory
|
128MB internal flash memory |
|
PHYSICAL SPECIFICATION
|
|
|
Dimensions
|
96,7 x 33,4 x 27,5 mm (L x W x H) |
|
OPERATING ENVIRONMENT
|
|
|
Operating temperature (without battery)
|
-40 °C to +85 °C |
|
Storage temperature (without battery)
|
-40 °C to +85 °C |
|
Operating humidity
|
5% to 95% non-condensing |
|
Battery charge temperature
|
0 °C to +45 °C |
|
Battery discharge temperature
|
-20 °C to +60 °C |
|
Battery storage temperature
|
-20 °C to +45 °C for 1 month -20 °C to +35 °C for 6 months |
|
FEATURES
|
|
|
Sensors
|
Accelerometer |
|
Scenarios
|
Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip |
|
Sleep modes
|
GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
|
Configuration and firmware update
|
FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration) |
|
SMS
|
Configuration, Events, Debug |
|
GPRS commands
|
Configuration, Debug |
|
Time Synchronization
|
GPS, NITZ, NTP |
|
Ignition detection
|
Accelerometer, External Power Voltage |
